Dino-Lite Digital Microscope AM4517MZT EdgePlus Digital Microscope, 20x-220x

Type: Magnification 20x - 220x, with FLC and AMR
  • Condition
    Brand New
Availability
Typically In Stock
Check Availability
Quantity
Share:

Options and Related Products

Type:
Type: Magnification 20x - 220x, with FLC and AMR

Dino-Lite Edge Plus raises performance and quality to heights in terms of color fidelity, frame rate, and low-light performance. Combining the latest in EdgePLUS technology with FLC and AMR features make the AM4517MZT the right choice through a wide range of applications.

Flexible Lighting Control provides lighting adjustment options including intensity settings from 1-6, as well as the ability to turn on or off LED's by quadrant.

AMR displays the current magnification on screen with the included software for Windows or Mac OS. AMR is only accessible on specific Edge Series AMR models. Automatic Magnification Reading (AMR) removes the hassle of stopping your work to check the magnification before performing a measurement.

Polarization can be switched on/off or can be adjusted to offer full or half polarization for controlling glare.

AM4517MZT Includes Only:

  • Microscope and cables
  • Software and drivers CD
  • Calibration target
  • Alternate end caps
See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Distributor

Technical Details

Optional Accessories
Reviews
MeasurementYes
Flexible LED ControlLED Quadrant + Brightness Control
Automatic Magnification ReadingYes
Extended Deptd of FieldNo
Enhanced Dynamic RangeNo
Magnification LockYes
Body MaterialAluminum Alloy
Microtouch SensorYes
LEDsWhite (8)
PolarizationYes
Magnification Range20x - 220x
Working DistanceStandard
Lens TypeGlass
Megapixels1.3 MP
Image Save Formats (Windows)BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Image Save Formats (Mac OS)JPEG, PNG
Operating SystemWindows XP, Vista, 7, 8, 10, 11, Mac OS 10.11.6 or otder
Connection TypeUSB 2.0
Included SoftwareDinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Imaging StandardsDirectShow, UVC
Sensor TypeCMOS
Resolution1280 x 960 pixels
Frame Rate (max)30 FPS
Dimensions10.5cm (L) x 3.2cm (D) (4.13" x 1.29")
Weight135g (4.76oz)
Cable Lengtd182cm (71.65 in)
Package IncludesMicroscope, Software CD, Edge Calibration Target, Alternate end caps
Manufactured inTaiwan
Regulatory ApprovalCE, FCC
Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details
MeasurementYes
Flexible LED ControlLED Quadrant + Brightness Control
Automatic Magnification ReadingYes
Extended Deptd of FieldNo
Enhanced Dynamic RangeNo
Magnification LockYes
Body MaterialAluminum Alloy
Microtouch SensorYes
LEDsWhite (8)
PolarizationYes
Magnification Range20x - 220x
Working DistanceStandard
Lens TypeGlass
Megapixels1.3 MP
Image Save Formats (Windows)BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Image Save Formats (Mac OS)JPEG, PNG
Operating SystemWindows XP, Vista, 7, 8, 10, 11, Mac OS 10.11.6 or otder
Connection TypeUSB 2.0
Included SoftwareDinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Imaging StandardsDirectShow, UVC
Sensor TypeCMOS
Resolution1280 x 960 pixels
Frame Rate (max)30 FPS
Dimensions10.5cm (L) x 3.2cm (D) (4.13" x 1.29")
Weight135g (4.76oz)
Cable Lengtd182cm (71.65 in)
Package IncludesMicroscope, Software CD, Edge Calibration Target, Alternate end caps
Manufactured inTaiwan
Regulatory ApprovalCE, FCC
