Duran, 6530-27, Ace Glass Three Necks Spherical Flask with Flush Seal Bottom Outlet, 100 L
100L Reaction, Spherical, 4-Neck, 200mm Flange Top
Spherical 100L reaction flask with Schott-Duran style flat, ground flange and bottom valve assembly. Nominal flask O.D. is 610mm. Nominal flask I.D. is 596mm. Flask height is 570mm. Neck height is 75mm. Supplied with capacity reference gradations. Nominal flange I.D. is 200mm (8 inches). Uses 6517-31 clamp and 7855-884 CAPFE (PTFE encapsulated silicone) o-ring. Flask has three standard taper 45/50 side joints. 35/25 o-ring/ball joint connection off flush-seal valve. Each flask is supplied with one CAPFE (PTFE encapsulated silicone) o-ring.
